Missing attribute value when creating AD account by adding AD entitlements

Identity Security Cloud (ISC) ISC Discussion and Questions
,
1

Hi,

I am trying to create an AD account for an identity.

Here is the Create Account setting, which will create displayName with the “Full Name” identity attribute value.

image888×777 40.7 KB

However, we checked that the AD account created, the displayName value is empty.

image1911×669 30.2 KB

Although we tried to aggregate AD accounts again, it is still showing empty.

The identity does contains value for “Full Name”.

image1903×459 28.8 KB

We also checked the account event, it looks normal without error

image1920×641 38 KB

image979×301 13.2 KB

Actually, displayName is just one of the missing values, there are other attributes that do not have value, although we have set them on Create Account.

May I know is there any miss configuration resulting this behaviour?

Many thanks.

2

Hi @longinuschanGT

Can you please check in the account activity where the account was created, if it contains the displayname attribute in it?

This is very weird and i can only think if the attribute is in the excluded list of attributes for provisioning on source json.
Otherwise it should work with the configuration i see in attached screenshots.
I hope this helps.
Thank You.
Regards
Vikas.

3

Hi @longinuschanGT What attributes have you configured for Account ID and Account Name in the AD Account Schema?

4

@longinuschanGT -

Could you provide the provisioning policy form from the back end for the create operation.

https://developer.identitysoon.com/idn/api/v3/get-provisioning-policy/index.html

5

Hi Jeremy,

We configured distinguished name for account id and sAMAxxountName as account name.



Hi Kumar,

We got the following from the api:

image459×352 12.9 KB

Hi Vikas,

Thank you for the insight, we observe the following from Search:

image1044×389 20.3 KB

The specified directory service attribute or value does not exist.

However, we do observe existing AD accounts on the same OU as gtuser, has value on displayName, and displayName does exists on account schema.

image1903×346 13.7 KB

image1511×579 33.8 KB

6

HI @longinuschanGT The error you are getting indicates that one or more attribute mappings in your provisioning policy are not configured correctly, either the target attribute name is incorrect or the value doesn’t meet AD syntax constraints. It is not necessarily the displayName attribute causing the problem.

As @amit_1140 says, if you could post your povisioning policy we could review, but also you could start with a default provisioning policy and then add attributes to determine which one is causing the problem.

One to check first could be userPrincipalName - are you using a transform? Looking at your identity attribute values, make sure it’s not generating 2 “@”s in the value.

7

Hi Jeremy, thank you for the suggestion.

I am trying to isolate the isssue, I disabled most of the problematic create account attributes, except displayName.

Then I create gtuser20 again, which shows displayName is does not exist only.

image1063×786 35.4 KB



{
    "name": "Account",
    "description": null,
    "usageType": "CREATE",
    "fields": [
        {
            "name": "ObjectType",
            "transform": {
                "type": "static",
                "attributes": {
                    "value": "User"
                }
            },
            "attributes": {
                "cloudRequired": "true"
            },
            "isRequired": false,
            "type": "string",
            "isMultiValued": false
        },
        {
            "name": "distinguishedName",
            "transform": {
                "type": "rule",
                "attributes": {
                    "name": "Create Unique Account ID"
                }
            },
            "attributes": {
                "template": "CN=$(lanId),OU=Personal Accounts,----",
                "cloudMaxUniqueChecks": "50",
                "cloudRequired": "true"
            },
            "isRequired": false,
            "type": "string",
            "isMultiValued": false
        },
        {
            "name": "sAMAccountName",
            "transform": {
                "type": "identityAttribute",
                "attributes": {
                    "name": "lanId"
                }
            },
            "attributes": {
                "cloudMaxUniqueChecks": "50",
                "cloudMaxSize": "20",
                "cloudRequired": "true"
            },
            "isRequired": false,
            "type": "string",
            "isMultiValued": false
        },
        {
            "name": "manager",
            "transform": {
                "type": "rule",
                "attributes": {
                    "name": "Get Manager LDAP DN"
                }
            },
            "attributes": {
                "cloudRequired": "true"
            },
            "isRequired": false,
            "type": "string",
            "isMultiValued": false
        },
        {
            "name": "mail",
            "transform": null,
            "attributes": {},
            "isRequired": false,
            "type": "string",
            "isMultiValued": false
        },
        {
            "name": "password",
            "transform": {
                "type": "rule",
                "attributes": {
                    "name": "Create Password"
                }
            },
            "attributes": {
                "cloudRequired": "true"
            },
            "isRequired": false,
            "type": "secret",
            "isMultiValued": false
        },
        {
            "name": "givenName",
            "transform": null,
            "attributes": {},
            "isRequired": false,
            "type": "string",
            "isMultiValued": false
        },
        {
            "name": "sn",
            "transform": null,
            "attributes": {},
            "isRequired": false,
            "type": "string",
            "isMultiValued": false
        },
        {
            "name": "pwdLastSet",
            "transform": {
                "type": "static",
                "attributes": {
                    "value": "false"
                }
            },
            "attributes": {},
            "isRequired": false,
            "type": "boolean",
            "isMultiValued": false
        },
        {
            "name": "IIQDisabled",
            "transform": {
                "type": "static",
                "attributes": {
                    "value": "false"
                }
            },
            "attributes": {},
            "isRequired": false,
            "type": "boolean",
            "isMultiValued": false
        },
        {
            "name": "primaryGroupDN",
            "transform": {
                "type": "static",
                "attributes": {
                    "value": ""
                }
            },
            "attributes": {},
            "isRequired": false,
            "type": "string",
            "isMultiValued": false
        },
        {
            "name": "description",
            "transform": {
                "type": "identityAttribute",
                "attributes": {
                    "name": "section"
                }
            },
            "attributes": {},
            "isRequired": false,
            "type": "string",
            "isMultiValued": false
        },
        {
            "name": "telephoneNumber",
            "transform": {
                "type": "identityAttribute",
                "attributes": {
                    "name": "phone"
                }
            },
            "attributes": {},
            "isRequired": false,
            "type": "string",
            "isMultiValued": false
        },
        {
            "name": "msNPAllowDialin",
            "transform": null,
            "attributes": {},
            "isRequired": false,
            "type": "string",
            "isMultiValued": false
        },
        {
            "name": "homeMDB",
            "transform": null,
            "attributes": {},
            "isRequired": false,
            "type": "string",
            "isMultiValued": false
        },
        {
            "name": "mailNickname",
            "transform": null,
            "attributes": {},
            "isRequired": false,
            "type": "string",
            "isMultiValued": false
        },
        {
            "name": "shadowAccountDN",
            "transform": null,
            "attributes": {},
            "isRequired": false,
            "type": "string",
            "isMultiValued": false
        },
        {
            "name": "msExchHideFromAddressLists",
            "transform": null,
            "attributes": {},
            "isRequired": false,
            "type": "boolean",
            "isMultiValued": false
        },
        {
            "name": "SipAddress",
            "transform": null,
            "attributes": {},
            "isRequired": false,
            "type": "string",
            "isMultiValued": false
        },
        {
            "name": "SipDomain",
            "transform": null,
            "attributes": {},
            "isRequired": false,
            "type": "string",
            "isMultiValued": false
        },
        {
            "name": "SipAddressType",
            "transform": null,
            "attributes": {},
            "isRequired": false,
            "type": "string",
            "isMultiValued": false
        },
        {
            "name": "msNPCallingStationID",
            "transform": null,
            "attributes": {},
            "isRequired": false,
            "type": "string",
            "isMultiValued": true
        },
        {
            "name": "msRADIUSCallbackNumber",
            "transform": null,
            "attributes": {},
            "isRequired": false,
            "type": "string",
            "isMultiValued": false
        },
        {
            "name": "msRADIUSFramedRoute",
            "transform": null,
            "attributes": {},
            "isRequired": false,
            "type": "string",
            "isMultiValued": true
        },
        {
            "name": "msRADIUSFramedIPAddress",
            "transform": null,
            "attributes": {},
            "isRequired": false,
            "type": "string",
            "isMultiValued": false
        },
        {
            "name": "RegistrarPool",
            "transform": null,
            "attributes": {},
            "isRequired": false,
            "type": "string",
            "isMultiValued": false
        },
        {
            "name": "dNSHostName",
            "transform": null,
            "attributes": {},
            "isRequired": false,
            "type": "string",
            "isMultiValued": false
        },
        {
            "name": "msDS-SupportedEncryptionTypes",
            "transform": null,
            "attributes": {},
            "isRequired": false,
            "type": "string",
            "isMultiValued": true
        },
        {
            "name": "msDS-ManagedPasswordInterval",
            "transform": null,
            "attributes": {},
            "isRequired": false,
            "type": "string",
            "isMultiValued": false
        },
        {
            "name": "msDS-GroupMSAMembership",
            "transform": null,
            "attributes": {},
            "isRequired": false,
            "type": "string",
            "isMultiValued": true
        },
        {
            "name": "msDS-AllowedToActOnBehalfOfOtherIdentity",
            "transform": null,
            "attributes": {},
            "isRequired": false,
            "type": "string",
            "isMultiValued": true
        },
        {
            "name": "servicePrincipalName",
            "transform": null,
            "attributes": {},
            "isRequired": false,
            "type": "string",
            "isMultiValued": true
        },
        {
            "name": "externalEmailAddress",
            "transform": null,
            "attributes": {},
            "isRequired": false,
            "type": "string",
            "isMultiValued": false
        },
        {
            "name": "userPrincipalName",
            "transform": null,
            "attributes": {},
            "isRequired": false,
            "type": "string",
            "isMultiValued": false
        },
        {
            "name": "title",
            "transform": {
                "type": "identityAttribute",
                "attributes": {
                    "name": "jobTitle"
                }
            },
            "attributes": {},
            "isRequired": false,
            "type": "string",
            "isMultiValued": false
        },
        {
            "name": "department",
            "transform": null,
            "attributes": {},
            "isRequired": false,
            "type": "string",
            "isMultiValued": false
        },
        {
            "name": "employeeID",
            "transform": null,
            "attributes": {},
            "isRequired": false,
            "type": "string",
            "isMultiValued": false
        },
        {
            "name": "company",
            "transform": null,
            "attributes": {},
            "isRequired": false,
            "type": "string",
            "isMultiValued": false
        },
        {
            "name": "division",
            "transform": null,
            "attributes": {},
            "isRequired": false,
            "type": "string",
            "isMultiValued": false
        },
        {
            "name": "cn",
            "transform": {
                "type": "identityAttribute",
                "attributes": {
                    "name": "lanId"
                }
            },
            "attributes": {},
            "isRequired": false,
            "type": "string",
            "isMultiValued": false
        },
        {
            "name": "extensionAttribute1",
            "transform": null,
            "attributes": {},
            "isRequired": false,
            "type": "string",
            "isMultiValued": false
        },
        {
            "name": "extensionAttribute2",
            "transform": {
                "type": "identityAttribute",
                "attributes": {
                    "name": "nickName"
                }
            },
            "attributes": {},
            "isRequired": false,
            "type": "string",
            "isMultiValued": false
        },
        {
            "name": "extensionAttribute3",
            "transform": {
                "type": "identityAttribute",
                "attributes": {
                    "name": "chineseName"
                }
            },
            "attributes": {},
            "isRequired": false,
            "type": "string",
            "isMultiValued": false
        },
        {
            "name": "extensionAttribute5",
            "transform": {
                "type": "identityAttribute",
                "attributes": {
                    "name": "accountOwner"
                }
            },
            "attributes": {},
            "isRequired": false,
            "type": "string",
            "isMultiValued": false
        },
        {
            "name": "extensionAttribute8",
            "transform": {
                "type": "identityAttribute",
                "attributes": {
                    "name": "section"
                }
            },
            "attributes": {},
            "isRequired": false,
            "type": "string",
            "isMultiValued": false
        },
        {
            "name": "extensionAttribute10",
            "transform": null,
            "attributes": {},
            "isRequired": false,
            "type": "string",
            "isMultiValued": false
        },
        {
            "name": "dirSyncEnabled",
            "transform": {
                "type": "static",
                "attributes": {
                    "value": "true"
                }
            },
            "attributes": {},
            "isRequired": false,
            "type": "string",
            "isMultiValued": false
        },
        {
            "name": "displayName",
            "transform": {
                "type": "identityAttribute",
                "attributes": {
                    "name": "fullName"
                }
            },
            "attributes": {},
            "isRequired": false,
            "type": "string",
            "isMultiValued": false
        }
    ]
}

Which shows the “displayName” transfrom is getting Full Name identity attribute.

8

Hi @longinuschanGT - I’m not sure that dirSyncEnabled is an AD attribute. Also you don’t appear to be populating userPrincipalName
